Product Overview: Precision Engineering for the Shop Floor

Our crossed roller slewing bearing series is not an off-the-shelf commodity; it is a precision instrument designed for the heart of your machine tool.
  • Optimized Roller Geometry: We utilize ground cylindrical rollers arranged in alternating perpendicular directions. This configuration allows a single bearing unit to simultaneously support radial, axial, and moment loads, eliminating the need for multiple bearing sets and reducing the overall footprint of the rotary table.
  • Preloaded for Zero Play: Every bearing undergoes a precise preloading process during assembly. By carefully adjusting the internal clearance, we eliminate all axial and radial play, creating a high rigidity rotary table bearing that resists deformation under cutting torque. This ensures repeatability in the micron range.
  • Integrated Gear Options: For direct-drive rotary tables, we offer bearings with integrated internal or external gears. These gears are hard-finished and ground to DIN Class 5 or better, ensuring smooth engagement with the torque motor and minimizing transmission error.
  • Low-Friction Design: Despite the high preload, our optimized raceway geometry and premium lubrication channels ensure low starting and running torque. This is critical for low friction rotary bearing applications where smooth, jitter-free motion at low speeds is essential for fine surface finishes.


Key Features: Engineered for Uncompromising Accuracy

  • Exceptional Moment Load Capacity: The crossed roller design offers up to 3x the moment load capacity of comparable ball bearings, making it ideal for 5-axis machining center slew ring applications where overhang loads are significant.
  • Ultra-Low Backlash (< 0.01mm): Our tight tolerance manufacturing ensures virtually zero backlash, crucial for maintaining path accuracy during complex 3D profiling and simultaneous 5-axis interpolation.
  • High Rotational Accuracy: Manufactured to P4 grade crossed roller bearing standards (with P2 available on request), our bearings deliver exceptional runout control, ensuring the spindle axis remains perfectly aligned with the workpiece.
  • Compact & Lightweight: By combining multiple load functions into a single compact unit, we allow machine designers to create lighter, more agile rotary axes without sacrificing structural integrity.
  • Sealed for Longevity: Equipped with multi-lip seals and efficient grease distribution channels, our machine tool rotation solution protects against coolant ingress and chip contamination, extending service life in harsh shop floor environments.


Applications: Powering the Next Generation of CNC Machines

Our crossed roller slewing bearings for CNC machine tools are the trusted choice for critical motion axes in:
  • 5-Axis Machining Centers: Serving as the core rotation element for A/C axes in gantry mills and vertical machining centers, enabling complex aerospace and mold-making operations.
  • CNC Rotary Tables: Providing the foundation for high-precision indexing tables used in die/mold manufacturing and automotive component production.
  • Tilting Heads & Trunnions: Supporting the heavy spindle heads in tilting-head configurations, ensuring stability during aggressive cutting strategies.
  • Mill-Turn Centers: Facilitating the precise rotation of the B-axis in mill-turn machines, allowing for complete part machining in a single setup.
  • Precision Grinding Machines: Used in rotary worktables where nanometer-level surface finishes are required, benefiting from our bearing's smooth motion and high stiffness.
