    In the world of heavy construction and logistics, a crane is only as good as its ability to rotate smoothly under extreme loads. The component that makes this possible—the slewing bearing—is often the most stressed part of the entire machine. For decades, the industry standard for balancing high load capacity with compact design has been the Single-Row Four-Point Contact Ball Bearing.
Request a Quote
Custom slew bearing for Spain customerCustom slew bearing for Spain customer
Custom slew bearing for UnitedKingdom customerCustom slew bearing for UnitedKingdom customer
Slew bearing for Brazll customerSlew bearing for Brazll customer
Slewing bearings exported to RusslaSlewing bearings exported to Russla
Slewing bearings for UnitedStates customerSlewing bearings for UnitedStates customer
Slewing ring exported to Southeast AsiaSlewing ring exported to Southeast Asia
Slewing ring exported to Southwest AsiaSlewing ring exported to Southwest Asia
Slewing ring exported to North AmericaSlewing ring exported to North America
Slewing ring exported to South AmericaSlewing ring exported to South America
Slewing ring exported to South AfricaSlewing ring exported to South Africa
Slew bearing for India customerSlew bearing for India customer
Slew bearing for Latin America customerSlew bearing for Latin America customer
Slewing bearing for Türkiye customerSlewing bearing for Türkiye customer
Slewing bearing for Uzbekistan customerSlewing bearing for Uzbekistan customer
Slewing ring exported to South KoreaSlewing ring exported to South Korea
Slewing ring exported to MexicoSlewing ring exported to Mexico
Custom slew bearing for Mexico customerCustom slew bearing for Mexico customer
Custom slew bearing for Italy customerCustom slew bearing for Italy customer
Custom slew bearing for Vietnam customerCustom slew bearing for Vietnam customer
Slewing bearing for Europe customerSlewing bearing for Europe customer


Why the Single-Row Four-Point Design Dominates Crane Applications

The "four-point contact" geometry is not just a marketing term; it is a mechanical necessity for cranes. In this design, a single row of balls contacts the raceway at four distinct points (two on the inner ring, two on the outer). This unique arrangement allows one bearing to simultaneously support:
  • Axial Loads: The immense vertical weight of the jib, counterweights, and payload.
  • Radial Loads: Horizontal forces generated by wind pressure and slewing acceleration.
  • Overturning Moments: The tipping force created when the boom extends outward with a load.

By consolidating these three load vectors into a single-row slewing ring, we achieve a significantly more compact and lighter solution compared to double-row or cross-roller alternatives, without sacrificing structural integrity. This compactness is crucial for minimizing the overall height of the crane's turntable, improving stability and center-of-gravity calculations.


Key Features Engineered for the Job Site

Cranes operate in some of the harshest environments on earth—from freezing offshore platforms to dusty desert construction sites. Our heavy-duty crane bearings are built to survive:
  1. Optimized Raceway Hardening: We utilize advanced induction hardening techniques to create a deep, wear-resistant layer on the raceways. This ensures the bearing can withstand millions of rotation cycles under full load without spalling or pitting, a common failure mode in cheaper alternatives.
  2. Precision-Machined External Gears: Most crane applications require an external gear drive. Our gears are cut with high precision (DIN Class 9 or better) and hardened to match the raceway durability. We offer custom module and tooth count options to seamlessly integrate with your existing slew drives or hydraulic motors.
  3. Robust Sealing Systems: Dust and moisture are the enemies of rotation. Our bearings feature multi-labyrinth seals combined with high-quality NBR or Viton lip seals. This design effectively blocks concrete dust, sand, and salt spray while retaining grease, ensuring long service intervals even in extreme operating conditions.
  4. High-Strength Steel Core: We exclusively use vacuum-degassed alloy steels (such as 42CrMo4 and 50Mn) known for their high toughness and fatigue resistance. This material choice is critical for preventing catastrophic failure under shock loads, such as sudden braking or emergency stops.
  5. Segmented Options for Large Diameters: For massive tower cranes requiring diameters over 2 meters, we offer segmented ring designs. These allow for easier transport and on-site assembly while maintaining the structural continuity of a monolithic ring through precision-machined joints.


Applications Across the Crane Spectrum

Our single-row four-point contact ball bearings are the go-to solution for a wide variety of lifting machinery:
  • Tower Cranes: Used in the slewing unit connecting the mast to the jib. They must handle enormous overturning moments as the jib lengthens and retracts.
  • Mobile Telescopic Cranes: Essential for the upper structure rotation, providing smooth control for precise load placement in urban construction.
  • Crawler Cranes: Supporting the massive weight of the superstructure on the undercarriage, these bearings endure continuous rotation on uneven ground.
  • Floating Cranes & Offshore Vessels: Designed with enhanced corrosion protection to resist saltwater exposure while handling dynamic wave-induced loads.
  • Rail-Mounted Gantry Cranes (RMG): Facilitating the rotation of spreaders in port logistics, where reliability and uptime are paramount.
