    In standard automation, precision is king. But in environments like aluminum foundries, glass manufacturing lines, or forging presses, precision is useless if the component fails due to heat. Standard bearings, designed for ambient temperatures, quickly lose their hardness, suffer from dimensional expansion that locks up movement, or see their lubricants carbonize when exposed to sustained temperatures above 120°C. This is where our High-Temperature Crossed Roller Slewing Bearings for Industrial Robots become the difference between a halted production line and continuous throughput.
Request a Quote
Custom slew bearing for Spain customerCustom slew bearing for Spain customer
Custom slew bearing for UnitedKingdom customerCustom slew bearing for UnitedKingdom customer
Slew bearing for Brazll customerSlew bearing for Brazll customer
Slewing bearings exported to RusslaSlewing bearings exported to Russla
Slewing bearings for UnitedStates customerSlewing bearings for UnitedStates customer
Slewing ring exported to Southeast AsiaSlewing ring exported to Southeast Asia
Slewing ring exported to Southwest AsiaSlewing ring exported to Southwest Asia
Slewing ring exported to North AmericaSlewing ring exported to North America
Slewing ring exported to South AmericaSlewing ring exported to South America
Slewing ring exported to South AfricaSlewing ring exported to South Africa
Slew bearing for India customerSlew bearing for India customer
Slew bearing for Latin America customerSlew bearing for Latin America customer
Slewing bearing for Türkiye customerSlewing bearing for Türkiye customer
Slewing bearing for Uzbekistan customerSlewing bearing for Uzbekistan customer
Slewing ring exported to South KoreaSlewing ring exported to South Korea
Slewing ring exported to MexicoSlewing ring exported to Mexico
Custom slew bearing for Mexico customerCustom slew bearing for Mexico customer
Custom slew bearing for Italy customerCustom slew bearing for Italy customer
Custom slew bearing for Vietnam customerCustom slew bearing for Vietnam customer
Slewing bearing for Europe customerSlewing bearing for Europe customer


Product Deep Dive: Engineering for the Heat Zone

The crossed roller design is already favored in robotics for its compact size and high rigidity. However, adapting this architecture for high-temperature applications requires addressing three critical failure points: material softening, clearance loss, and lubrication breakdown.
  • Dimensional Stability & Special Steel: We utilize vacuum-degassed bearing steels subjected to a proprietary high-temperature tempering process. This stabilizes the microstructure, ensuring the rings and rollers retain their hardness (HRC 58+) even after prolonged exposure to temperatures up to 250°C (482°F). Unlike standard steels that soften and deform, our material maintains its structural integrity.
  • Thermal Clearance Compensation: One of the biggest risks in hot environments is "seizing." As metal expands, internal clearance disappears, causing friction and eventual lock-up. Our engineers calculate the specific thermal expansion coefficients of the housing and the bearing to preset a special clearance. This ensures that when the bearing reaches operating temperature, the internal play settles into the optimal range for smooth rotation rather than binding.
  • Advanced High-Temp Lubrication: We partner with leading lubricant suppliers to fill these bearings with synthetic high-temperature greases (e.g., PFPE or specialized lithium-complex variants) that resist oxidation and carbonization up to 300°C. For extreme cases, we can design units compatible with dry-film lubricants or solid lubricant inserts.
  • Heat-Resistant Sealing: Standard nitrile seals harden and crack in the heat. Our industrial robot wrist bearing solutions feature seals made from Fluoroelastomer (FKM/Viton) or Silicone compounds, which maintain elasticity and sealing effectiveness in scorching conditions, keeping contaminants out and lubricant in.


Key Features: Built to Withstand the Burn

  • Rated for Extreme Heat: Continuously operational at temperatures up to 250°C, with peak tolerance even higher for short durations. Ideal for glass handling robot slew ring applications near furnaces.
  • Zero Seizure Guarantee: Our pre-calculated special clearance bearing for heat design prevents thermal locking, ensuring smooth start-up and operation even after the robot has been idle in a hot zone.
  • Maintained Rigidity: Despite the heat, the crossed roller configuration provides exceptional moment load capacity, allowing robots to handle heavy payloads with minimal deflection.
  • Long Service Intervals: The combination of heat-stable grease and effective sealing drastically extends relubrication intervals compared to standard bearings, reducing maintenance downtime in hazardous areas.
  • Compact & Lightweight: Retaining the space-saving benefits of crossed roller bearings, our high-temperature crossed roller slewing bearings allow for sleeker robot arm designs without sacrificing thermal performance.


Applications: Mastering the Hot Zones

Our bearings are the silent workhorses in some of the hottest industrial environments on earth:
  • Foundry & Metal Casting: Robots used for pouring molten metal, extracting castings from die-casting machines, and handling hot ingots rely on our foundry robot rotation bearing technology to survive radiant heat and splashes.
  • Glass Manufacturing: From blowing to annealing, glass robots operate near ovens reaching hundreds of degrees. Our bearings ensure precise placement of fragile glass products without stuttering or seizing.
  • Forging & Stamping: Loading and unloading red-hot billets into forging presses requires a heat-resistant robotic joint bearing that can withstand both high impact loads and intense ambient heat.
  • Ceramics & Brick Production: Handling green bricks into kilns and removing fired products demands reliability in dusty, high-temperature settings.
  • Heat Treatment Lines: Automated loading systems for carburizing and hardening furnaces utilize our bearings for consistent performance in controlled atmosphere ovens.
